describe-replication-instances — AWS CLI 2.15.39 Command Reference

Provides information that defines a replication instance.

ReplicationInstanceIdentifier -> (string)

The replication instance identifier is a required parameter. This parameter is stored as a lowercase string.

Constraints:

• Must contain 1-63 alphanumeric characters or hyphens.
• First character must be a letter.
• Cannot end with a hyphen or contain two consecutive hyphens.

Example: myrepinstance

ReplicationInstanceClass -> (string)

The compute and memory capacity of the replication instance as defined for the specified replication instance class. It is a required parameter, although a default value is pre-selected in the DMS console.

For more information on the settings and capacities for the available replication instance classes, see Selecting the right DMS replication instance for your migration .

ReplicationInstanceStatus -> (string)

The status of the replication instance. The possible return values include:

• "available"
• "creating"
• "deleted"
• "deleting"
• "failed"
• "modifying"
• "upgrading"
• "rebooting"
• "resetting-master-credentials"
• "storage-full"
• "incompatible-credentials"
• "incompatible-network"
• "maintenance"

AllocatedStorage -> (integer)

The amount of storage (in gigabytes) that is allocated for the replication instance.

InstanceCreateTime -> (timestamp)

The time the replication instance was created.

VpcSecurityGroups -> (list)

The VPC security group for the instance.

(structure)

Describes the status of a security group associated with the virtual private cloud (VPC) hosting your replication and DB instances.

VpcSecurityGroupId -> (string)

The VPC security group ID.

Status -> (string)

The status of the VPC security group.

AvailabilityZone -> (string)

The Availability Zone for the instance.

ReplicationSubnetGroup -> (structure)

The subnet group for the replication instance.

ReplicationSubnetGroupIdentifier -> (string)

The identifier of the replication instance subnet group.

ReplicationSubnetGroupDescription -> (string)

A description for the replication subnet group.

VpcId -> (string)

The ID of the VPC.

SubnetGroupStatus -> (string)

The status of the subnet group.

Subnets -> (list)

The subnets that are in the subnet group.

(structure)

In response to a request by the DescribeReplicationSubnetGroups operation, this object identifies a subnet by its given Availability Zone, subnet identifier, and status.

SubnetIdentifier -> (string)

The subnet identifier.

SubnetAvailabilityZone -> (structure)

The Availability Zone of the subnet.

Name -> (string)

The name of the Availability Zone.

SubnetStatus -> (string)

The status of the subnet.

SupportedNetworkTypes -> (list)

The IP addressing protocol supported by the subnet group. This is used by a replication instance with values such as IPv4 only or Dual-stack that supports both IPv4 and IPv6 addressing. IPv6 only is not yet supported.

(string)

PreferredMaintenanceWindow -> (string)

The maintenance window times for the replication instance. Any pending upgrades to the replication instance are performed during this time.

PendingModifiedValues -> (structure)

The pending modification values.

ReplicationInstanceClass -> (string)

AllocatedStorage -> (integer)

The amount of storage (in gigabytes) that is allocated for the replication instance.

MultiAZ -> (boolean)

Specifies whether the replication instance is a Multi-AZ deployment. You can’t set the AvailabilityZone parameter if the Multi-AZ parameter is set to true .

EngineVersion -> (string)

The engine version number of the replication instance.

NetworkType -> (string)

The type of IP address protocol used by a replication instance, such as IPv4 only or Dual-stack that supports both IPv4 and IPv6 addressing. IPv6 only is not yet supported.

MultiAZ -> (boolean)

Specifies whether the replication instance is a Multi-AZ deployment. You can’t set the AvailabilityZone parameter if the Multi-AZ parameter is set to true .

EngineVersion -> (string)

The engine version number of the replication instance.

If an engine version number is not specified when a replication instance is created, the default is the latest engine version available.

When modifying a major engine version of an instance, also set AllowMajorVersionUpgrade to true .

AutoMinorVersionUpgrade -> (boolean)

Boolean value indicating if minor version upgrades will be automatically applied to the instance.

KmsKeyId -> (string)

An KMS key identifier that is used to encrypt the data on the replication instance.

If you don’t specify a value for the KmsKeyId parameter, then DMS uses your default encryption key.

KMS creates the default encryption key for your Amazon Web Services account. Your Amazon Web Services account has a different default encryption key for each Amazon Web Services Region.

ReplicationInstanceArn -> (string)

The Amazon Resource Name (ARN) of the replication instance.

ReplicationInstancePublicIpAddress -> (string)

The public IP address of the replication instance.

ReplicationInstancePrivateIpAddress -> (string)

The private IP address of the replication instance.

ReplicationInstancePublicIpAddresses -> (list)

One or more public IP addresses for the replication instance.

(string)

ReplicationInstancePrivateIpAddresses -> (list)

One or more private IP addresses for the replication instance.

(string)

ReplicationInstanceIpv6Addresses -> (list)

One or more IPv6 addresses for the replication instance.

(string)

PubliclyAccessible -> (boolean)

Specifies the accessibility options for the replication instance. A value of true represents an instance with a public IP address. A value of false represents an instance with a private IP address. The default value is true .

SecondaryAvailabilityZone -> (string)

The Availability Zone of the standby replication instance in a Multi-AZ deployment.

FreeUntil -> (timestamp)

The expiration date of the free replication instance that is part of the Free DMS program.

DnsNameServers -> (string)

The DNS name servers supported for the replication instance to access your on-premise source or target database.

NetworkType -> (string)

The type of IP address protocol used by a replication instance, such as IPv4 only or Dual-stack that supports both IPv4 and IPv6 addressing. IPv6 only is not yet supported.
